This LED batten light is a high-performance indoor illumination solution designed for versatile mounting applications including surface, suspended, wall, and ceiling configurations. Constructed with a robust metal base and a durable polycarbonate diffuser, this 1225mm fixture provides a sleek and professional aesthetic suitable for various commercial and residential environments. The unit features a painted white back plate and is engineered to be mounted into internal corners, offering flexibility in spatial design and lighting layout.
Operating on a standard voltage range of 220V-240V, this fixture integrates a 40W LED system that delivers a substantial luminous flux of 3630 lumens. The light source maintains a colour temperature of 4000K, producing a crisp cool white output with a colour rendering index of 80 for accurate visual representation. With a wide beam angle of 120 degrees, the luminaire ensures broad and even light distribution across the intended area, minimizing shadows and enhancing visibility.
Installation is streamlined through the inclusion of a large terminal block designed for looping and easy wiring, complemented by the ability to be directly screw mounted. The system is SAA-approved and features an integral driver, ensuring compliance with safety standards and reliable electrical performance. For specialized mounting requirements, the fixture is compatible with stainless steel clips that facilitate quick installation without the need for dismantling the lighting components.
This IP20-rated indoor lighting solution is backed by a one-year warranty, reflecting its build quality and long-term reliability. The combination of high-efficiency LED technology and a 4-foot batten form factor makes it an ideal choice for garages, commercial spaces, and general indoor utility lighting. Its functional design and technical specifications provide a dependable and energy-efficient alternative to traditional fluorescent lighting systems.
PRODUCT TYPE: LED Batten Light
APPLICATIONS: Indoor; can be mounted into internal corners
WARRANTY: 1 year
COMPLIANCE: SAA-approved (integral driver)
COLOUR: White (back plate)
MATERIAL: Metal (base); polycarbonate (diffuser)
IP RATING: Indoors only
LUMENS: 3630lm
COLOUR TEMP: 4000K (cool white)
VOLTAGE: 220V-240V
LED WATTAGE: 40W
DRIVER: Included
GLOBE: LED
GLOBE INCLUDED: Yes (built-in)
DIMENSIONS: 1225mm (length) x 60mm (width) x 60mm (height)
MOUNTING: Surface mounted; suspended; wall mounted; ceiling mounted
CRI: 80
BEAM ANGLE: 120°
PHOTOMETRIC DATA: Available upon request
INSTALLATION: Large terminal block for looping; easy wire
ACCESSORIES: Set of 2 stainless steel clips for quick installation without dismantling of lighting fixtures (sold separately)
FEATURES: Painted white back plate; 4 foot batten
REMARKS: Can be directly screw mounted
