This hand dryer is a high-performance solution engineered for heavy traffic environments such as airports, large hotels, and sports centers. Constructed with a 1.5mm thick AISI 304 stainless steel cover and a robust aluminium base plate, it offers exceptional durability and anti-vandalism features. The unit operates on a 220V-240V supply, drawing 10A of current to power a 250W motor and a 2,000W NiCr heating element for efficient moisture removal.
Technical performance is characterized by an air speed of 100km/h and an air temperature of 50 degrees Celsius at a distance of 10cm, resulting in a drying time of approximately 29 seconds. The internal mechanism features a fan wheel made of aluminium and a fan scroll composed of fire-resistant UL 94-V0 plastic, ensuring long-term reliability and safety. The motor operates at 5,500 RPM while maintaining a relatively low noise level of 68 dBA, aided by four silent blocks that eliminate vibrations during operation.
User interaction is facilitated by an adjustable motion sensor that utilizes a potentiometer for precise detection range settings. The system initiates an automatic start when hands are positioned under the 360-degree rotating chrome-plated Zamak nozzle and continues operation as long as hands remain within the sensor field. For energy efficiency and safety, the device automatically ceases operation two seconds after hands are removed from the detection zone, providing a seamless and hygienic user experience.
Installation is streamlined via a base plate equipped with four 8mm diameter holes for secure wall mounting, making it suitable for various official organizations and recreational areas. This Class I rated appliance carries multiple certifications including CE, GS, EMC, RoHS, and CB Scheme, reflecting its compliance with international safety and quality standards. With dimensions of 245mm in height and 276mm in width, this 4.65kg unit represents a compact yet powerful solution for modern commercial washroom facilities.
PRODUCT TYPE: Hand Dryer
APPLICATIONS: Airports; large hotels; sport centers; large recreational areas; large official organizations; heavy traffic bathrooms
MADE IN: Europe
WARRANTY: 5 years (2 years labour, 5 years parts)
COLOUR: Satin (finish)
MATERIAL: Stainless steel AISI 304 (cover); aluminium (base plate); fire resistant plastic UL 94-V0 (fan scroll); aluminium (fan wheel); chrome plated Zamak (nozzle)
IP RATING: IP21 (indoors)
VOLTAGE: 220V-240V (50/60Hz)
WATTAGE: 2250W
DIMENSIONS: 245mm (height) x 276mm (width) x 214mm (depth)
WEIGHT: 4.65kg
CLASS: I
RPM: 5,500
MOTOR: 250W
NOISE: 68 dBA
MOTION SENSOR: Yes (adjustable detection by means of a potentiometer)
OPERATION: Automatic start when hands are placed under the rotating nozzle; continuous operation while hands remain within sensor detection range; stops 2 seconds after hands are removed
INSTALLATION: Base plate with 4 Ø 8 mm holes for wall mounting
HEATING ELEMENT: 2,000W (NiCr on a mica frame with thermal cut-off)
COVER THICKNESS: 1.5mm
DRYING TIME: 29 seconds
AIR SPEED: 100km/h
AIR TEMPERATURE: 50°C (at 10cm distance/21°C)
CONSUMPTION: 10A
FEATURES: Easy maintenance; low noise levels; high level of user safety; powerful airflow; 360° rotating nozzle; anti-vandalism features; long durability; complete reliability; silent blocks (4 units assembled in the rear part of the base plate to eliminate vibrations)
CERTIFICATIONS: CE; GS; EMC; RoHS; CB Scheme
