This hand dryer is a high-performance solution engineered for heavy traffic environments such as airports, large hotels, and sports centers. Constructed with a robust 1.5mm thick white steel cover and an aluminum base plate, the unit ensures long-term durability and incorporates anti-vandalism features for secure installation in public facilities. The device operates on a 220V-240V supply, drawing 10A of current to power a 250W motor and a 2,000W NiCr heating element on a mica frame with integrated thermal cut-off.
Technical performance is characterized by a powerful airflow reaching speeds of 100km/h and a drying time of approximately 29 seconds. The internal fan system utilizes an aluminum fan wheel and a fire-resistant plastic UL 94-V0 fan scroll, rotating at 5,500 RPM to deliver consistent air volume. At a distance of 10cm, the air temperature reaches 50°C, providing an efficient and comfortable drying experience while maintaining a relatively low noise level of 68 dBA through the use of four silent blocks designed to eliminate vibrations.
User interaction is facilitated by an advanced automatic motion sensor with adjustable detection sensitivity via a potentiometer, allowing for precise calibration based on the installation environment. The 360-degree rotating nozzle, crafted from chrome-plated Zamak, offers versatile airflow direction, while the automatic start-stop mechanism ensures energy efficiency by ceasing operation two seconds after hands are removed from the sensor range.
Installation is streamlined through a base plate featuring four 8mm mounting holes for secure surface attachment to walls. Measuring 245mm in height, 276mm in width, and 214mm in depth with a total weight of 4.65kg, the unit is compact yet powerful enough for demanding commercial applications. Certified under CE, GS, EMC, RoHS, and the CB Scheme, this hand dryer represents a reliable, safe, and easy-to-maintain hygiene solution for any high-occupancy professional setting.
PRODUCT TYPE: Hand Dryer
APPLICATIONS: Airports; large hotels; sport centers; large recreational areas; large official organizations; heavy traffic bathrooms
MADE IN: Europe
WARRANTY: 5 years (2 years labour, 5 years parts)
COLOUR: White (finish)
MATERIAL: Steel (cover); aluminium (base plate); fire resistant plastic UL 94-V0 (fan scroll); aluminium (fan wheel); chrome plated Zamak (nozzle)
IP RATING: IP21 (indoors)
VOLTAGE: 220V-240V (50/60Hz)
WATTAGE: 2250W
DIMENSIONS: 245mm (height) x 276mm (width) x 214mm (depth)
WEIGHT: 4.65kg
CLASS: I
RPM: 5,500
MOTOR: 250W
NOISE: 68 dBA
MOTION SENSOR: Yes (adjustable detection by means of a potentiometer)
OPERATION: Automatic start when hands are placed under the rotating nozzle; continuous operation while hands remain within sensor detection range; stops 2 seconds after hands are removed
INSTALLATION: Base plate with 4 Ø 8 mm holes for wall mounting
HEATING ELEMENT: 2,000W (NiCr on a mica frame with thermal cut-off)
COVER THICKNESS: 1.5mm
DRYING TIME: 29 seconds
AIR SPEED: 100km/h
AIR TEMPERATURE: 50°C (at 10cm distance/21°C)
CONSUMPTION: 10A
FEATURES: Easy maintenance; low noise levels; high level of user safety; powerful airflow; 360° rotating nozzle; anti-vandalism features; long durability; complete reliability; silent blocks (4 units assembled in the rear part of the base plate to eliminate vibrations)
CERTIFICATIONS: CE; GS; EMC; RoHS; CB Scheme
