This DALI to PWM non-isolated signal converter is a purpose-built bridge between intelligent DALI control and smooth PWM dimming, designed for lighting systems where precision and consistency matter. It enables reliable communication between a DALI interface and PWM-dimmable drivers, delivering a clean PWM dimming signal that helps achieve stable, repeatable light levels across a wide range of applications-from controlled horticultural environments to refined architectural and decorative installations.
Built for real-world conditions, the converter is housed in a waterproof IP67 enclosure that supports dependable operation in challenging indoor and semi-exposed settings where moisture, dust, or wash-down conditions can be a concern. With a wide operating temperature range and a fast start-up response, it’s engineered to maintain performance during seasonal changes, high-duty cycles, and demanding project environments, helping installers and specifiers deliver a lighting solution that behaves exactly as expected day after day.
On the control side, it supports DALI dimming with selectable logarithmic and linear dimming curves, allowing you to tailor the visual feel of fades and transitions to suit the space, the task, or the crop. The output dimming range is designed to provide confident low-end control and a true dim-to-off experience, creating comfortable ambience in residential and office spaces while also supporting the accuracy often required in commercial and horticultural lighting programs.
Designed with compliance and long-term ownership in mind, it meets key standards for electromagnetic compatibility and RoHS requirements, making it a reassuring choice for professional installations. Practical wiring compatibility and a robust build help streamline on-site work and reduce call-backs, while a 5-year warranty underscores the product’s quality and reliability-ideal for projects where performance, protection, and premium results are non-negotiable.
IP RATING: IP67
WARRANTY: 5 years
INPUT VOLTAGE: 10-22.5VDC
WORKING TEMPERATURE: -30°C~+60°C
DIMENSIONS: 111mm (Max) L x 30mm W x 30mm H
FEATURES: High performance & high reliability; PWM dimming signal output; Compatible with PWM dimmable drivers; Dimming range: 10%-100% (dim to off); Supports DALI dimming function (the logarithmic dimming curve and linear dimming curve can be selected via DALI interface); IP67 rating & waterproof casing
APPLICATIONS: Horticultural lighting; Indoor office lighting; Decorative lighting; Commercial lighting; Residential lighting
PWM RANGE: 10%-100% (dim to off)
PWM VOLTAGE: 10VDC
PWM SOURCE CURRENT: 5mA (max.)
PWM TOLERANCE: ±5%
FREQUENCY: 1kHz
TEMPERATURE DRIFT: ±5%
START-UP TIME: <1S@16Vdc DALI typical voltage
WORKING HUMIDITY: 20-90%RH (no condensation)
STORAGE TEMPERATURE: -30°C~+60°C (six months under class I environment)
STORAGE HUMIDITY: 10-90%RH (no condensation)
ATMOSPHERIC PRESSURE: 86KPa~106KPa
EMI: Complies with EN55015
ROHS: RoHS 2.0 (EU) 2015/863
DALI EXECUTIVE STANDARD: IEC 62386-101, 102, 103, 207
DALI PROTOCOL DETAILS: Includes 16 groups and 64 IP addresses
WIRE COMPATIBILITY: No. 22 to No.16 rubber wires or two-core or three-core sheathed wires
WIRE PREPARATION: Exposed length of wire cores: 4-6mm; Peeled length of sheathed wires: 14-16mm; Outer diameter of wires: 5-8mm
