This exhaust fan is engineered to provide efficient air extraction and integrated illumination for large interior spaces. Finished in matt white, it features a precision-balanced AC motor rated at 50W that delivers an airflow of 460m³/hr (128 l/sec) while maintaining a low noise level of 46dB at three metres. The fan operates on 220-240V AC / 50Hz and is classified as Class I for electrical safety, ensuring dependable performance in bathrooms, laundries and other moisture-laden environments.
The luminaire incorporates a fixed 15W LED light source producing a maximum output of 1100lm. A Tri-CCT function allows the user to select between 3000K warm white, 4200K cool white or 6000K daylight white colour temperatures, providing tailored lighting to suit different tasks or preferences. The LED chips are permanently integrated for long service life and stable photometric performance, eliminating the need for frequent globe replacement.
Practical installation is facilitated by swing clips with screws and a plug-and-lead connection that reduce wiring time. The unit fits a 300mm diameter ceiling cutout and includes both 100mm and 150mm duct outlets (duct not included) to accommodate larger ventilation systems. A fascia diameter of 330mm and overall height of 185mm ensure a discreet yet effective profile, while the removable fascia simplifies cleaning and routine maintenance.
For added convenience, the fan incorporates a built-in delay OFF timer adjustable up to 30 minutes, allowing continued extraction after the light or fan is switched off to remove residual humidity. Rated IPX4 for moisture resistance, it is supplied with a long 0.9m lead and packaged in fully recyclable cardboard with no polyfoam. Backed by a 3-year replacement warranty, this exhaust fan with integrated Tri-CCT LED provides a high-quality and reliable solution for large rooms requiring powerful ventilation and adaptable illumination.
COLOUR: White
IP RATING: IPX4
DIMENSIONS: 185mm (height) x 330mm (diameter), 30mm (fascia height)
CUTOUT: 300mm (diameter)
DUCT OUTLET DIAMETER: 100mm & 150mm (duct not included)
MOTOR TYPE: AC
MOTOR WATTS: 50W
AIRFLOW: 460m³/hr (128 l/sec)
NOISE: 46dB at 3m
VOLTAGE: 220-240V AC / 50Hz
GLOBE: LED (includes fixed LED chips in fitting)
LED WATTAGE: 15W
COLOUR TEMP: Switchable between 3000K (warm white), 4200K (cool white), 6000K (daylight white)
LUMENS: 1100lm (max)
CONTROL: Yes (AU plug and lead for fan and light)
CLASS: Class I
ROOM SUITABILITY: Large rooms
INCLUDES: 4-pin plug base
INSTALLATION: Swing clips with screws; plug and lead for faster installation; includes round cutout and long lead (0.9m)
FEATURES: Built-in delay OFF timer adjustable up to 30 mins; removable fascia for easy cleaning; polyfoam free packaging (100% recyclable cardboard); swing clips for easy clamping in any room; low resistance airflow path
NOTE: NCC requires an exhaust system that is not run continuously and installed in a room without windows to continue running for at least 10 minutes after it is switched OFF
WARRANTY: 3 years (replacement)
