This commercial grade LED downlight offers a precision-engineered lighting solution suitable for both residential and commercial environments. Designed with a recessed mounting profile, it integrates seamlessly into ceilings, providing a clean and unobtrusive finish. The luminaire utilises a high-performance 13W COB LED engine, delivering a maximum luminous flux of 1163lm at 5000K, with selectable output across five colour temperatures ranging from 2700K (warm white) to 5700K (daylight white). This ensures optimised visual comfort and adaptability across various applications, including task, ambient, and accent lighting.
Engineered for efficient operation, the downlight operates on a 200–240V 50–60Hz input and features a fixed LED chip set with a high CRI of ≥80, contributing to superior colour rendering and clarity. The integrated reflector design ensures a controlled 60° beam angle, producing a defined yet uniform light distribution. The unit is fully dimmable and equipped with a driver that allows colour temperature selection via an onboard DIP switch, providing versatile control without requiring component replacement or additional wiring.
The construction includes a robust IC-4 rated body, allowing installation in direct contact with thermal insulation. With a cutout compatibility of 80–85mm and overall face diameter of 110mm, the unit maintains an overall depth of 73mm, minimising ceiling cavity requirements. The downlight is rated IP44 from the underside when installed, making it resistant to dust and splashes and suitable for damp areas such as kitchens or sheltered outdoor ceilings.
Functionality is further enhanced by an adjustable gimbal mechanism, permitting directional control of the beam for precise illumination. This plug-and-play module includes a dimmable LED driver and flex and plug, simplifying installation and retrofitting into existing MR16 or click-in frame systems. Backed by a 3-year replacement warranty, this luminaire represents a high-quality, long-life solution for professional lighting installations demanding performance, efficiency, and adaptability.
COLOUR: White
IP RATING: IP44 (weather-resistant)
IC RATING: IC-4 (suitable for abutted and covered insulation)
DIMENSIONS: 110mm (diameter) x 73mm (depth)
CUTOUT: 80mm–85mm (diameter)
WATTAGE: 13W (max)
VOLTAGE: 200–240V 50–60Hz
GLOBE: LED (includes fixed LED chips in fitting)
COLOUR TEMP: Switchable between 2700K (warm white), 3000K (warm white), 4000K (cool white), 5000K (daylight white), 5700K (daylight white)
LUMENS: 1002lm (2700K), 995lm (3000K), 1098lm (4000K), 1163lm (5000K), 1145lm (5700K)
DIMMABLE: Yes
CRI: ≥80
BEAM ANGLE: 60°
LIFE SPAN: 50,000 hours
LED TYPE: COB
MOUNTING: Recessed
INCLUDES: Dimmable LED driver and flex and plug
INSTALLATION: Plug and play module and driver; suits most MR16 downlight frames; also compatible with click-in frames
CAPABILITIES: Adjustable gimbal (tiltable light head for directional control); colour temperature selectable via DIP switch on driver
WARRANTY: 3 years (replacement)
