This exhaust fan is engineered to deliver high-capacity mechanical ventilation for residential wet areas where effective moisture and odour removal is essential for maintaining healthy indoor air quality. The unit incorporates a powerful two-speed ball bearing motor with selectable 58W and 100W operating modes, enabling optimisation between energy consumption and maximum extraction performance. With an air extraction capacity of up to 600m³/hr, the system provides rapid air turnover suitable for bathrooms, toilets, and kitchens, contributing to the reduction of condensation, airborne contaminants, and humidity-related degradation of building materials.
The integrated 19W LED light source provides tri-CCT functionality, allowing selection between 3000K warm white, 4000K cool white, and 5000K daylight white to suit varying ambient and task lighting requirements. A maximum luminous flux of 1200lm ensures effective general illumination within the space, while the fixed LED architecture promotes long-term luminous stability and consistent chromatic performance over the operational lifespan of the luminaire. This dual-function design consolidates ventilation and lighting into a single ceiling-mounted system, improving installation efficiency and reducing fixture clutter.
The fan assembly is configured in a round form factor with a white fascia measuring 332mm in diameter and 203mm in height, with a 300mm cut-out size enabling recessed installation into standard ceiling cavities. The plastic construction provides electrical insulation and corrosion resistance suitable for humid internal environments, while the ball bearing motor architecture supports stable rotational performance and reduced mechanical wear under continuous operational cycles. A duct interface sized to 148mm facilitates effective airflow transfer into connected ducting systems, supporting efficient exhaust discharge to the exterior environment.
Supplied installation components, including a draft stopper, duct adaptor, and cut-out template, support accurate fitting and controlled airflow management within the ventilation pathway. The two-step fan speed control allows adaptable performance to match varying ventilation demands, enhancing operational flexibility across different room sizes and usage conditions. Designed for installation by a licensed electrician, this exhaust fan represents a technically robust and reliable ventilation solution, combining high airflow performance with integrated, adjustable LED illumination for functional and durable indoor environmental control.
COLOUR: White
MATERIAL: Plastic
DIMENSIONS: 332mm (diameter) x 203mm (height)
CUTOUT: 300mm (diameter)
WEIGHT: 3.9kg
MOTOR: Ball bearing motor
WATTAGE: 100W / 58W (two-speed motor)
GLOBE: LED (includes fixed LED chips in fitting)
LED WATTAGE: 19W
COLOUR TEMP: 3000K (warm white), 4000K (cool white), 5000K (daylight white)
LUMENS: 1200lm (max)
AIRFLOW: Up to 600m³/hr
DUCT SIZE: 148mm
OPERATION: 2 step fan speed control
INCLUDES: Draft stopper and duct adaptor; cut-out template
APPLICATIONS: Bathroom, toilet and kitchen
INSTALLATION: Must be installed by licensed electrician
WARRANTY: 1 year (replacement)
