This LED up down light delivers reliable and efficient exterior illumination with a sleek, contemporary profile. Engineered with a durable aluminium housing finished in matt white and a robust polycarbonate diffuser and mounting plate, it combines mechanical strength with refined aesthetics. Its compact form factor of 230 mm width, 72 mm height and 56 mm projection allows unobtrusive integration into modern façades while maintaining excellent light distribution. The IP65 weatherproof rating ensures full protection against dust ingress and high-pressure water jets, making it suitable for exposed outdoor installations in residential or commercial environments.
The luminaire operates on a standard 220-240 V AC 50/60 Hz supply and incorporates a fixed LED light source with a total power consumption of just 7 W. It produces a warm 3000 K light output with a luminous flux of 350 lm, delivering comfortable, low-glare illumination for pathways, entrances or architectural features. A colour rendering index greater than 80 provides accurate colour reproduction, while a broad 200° beam angle ensures uniform up and down lighting across adjacent surfaces. With a high power factor above 0.8, the driver maintains efficient energy utilisation and stable electrical performance.
Designed for longevity, the integrated LED system offers a life span of approximately 30,000 hours, reducing maintenance intervals and operating costs over its service life. The fitting is non-dimmable, ensuring consistent light output, and is compatible with 2-way switching and external PIR or microwave sensors to enable automated control strategies. Its operational temperature range of -20 °C to 50 °C supports reliable performance in diverse climatic conditions.
This LED up down light must be installed by a licenced electrician to ensure electrical safety and correct sealing of mounting screws and cable entries to preserve its IP65 rating. Supplied with a three-year replacement warranty, it represents a high-quality, energy-efficient solution for exterior wall lighting where durability, performance and modern design are equally critical.
COLOUR: Matt White
MATERIAL: Aluminium (powder coated), polycarbonate diffuser and mounting plate
DIMENSIONS: 230mm (width) x 72mm (height) x 56mm (projection)
IP RATING: IP65 (fully weatherproof)
VOLTAGE: 220-240V AC 50/60Hz
LED WATTAGE: 7W
GLOBE: LED (includes fixed LED chips in fitting)
COLOUR TEMP: 3000K (warm white)
LUMENS: 350lm
CRI: >80
BEAM ANGLE: 200°
POWER FACTOR: >0.8
AMBIENT TEMP: -20°C to 50°C
DIMMABLE: No
LIFE SPAN: 30,000 hours
MOUNTING: Surface mounted
OPERATION: Suitable for 2-way switching; suitable for use with PIR or microwave sensors
INSTALLATION: Must be installed by a licenced electrician
WARRANTY: 3 years (replacement)
