This commercial grade LED emergency batten light is engineered to deliver high-performance illumination in demanding environments where durability and reliability are essential. Operating at 40W, the integrated SMD LED system produces a luminous output of 5514lm at a 4000K cool white colour temperature, ensuring clear and consistent visibility. With a wide 120° beam angle and a CRI of 80, the fitting provides uniform light distribution and accurate colour rendering suitable for functional commercial and industrial applications.
Constructed from a robust polycarbonate housing paired with a frosted polycarbonate diffuser, this luminaire is designed to withstand harsh operating conditions while maintaining optimal light diffusion. The IP65 rating ensures full weatherproof protection against dust and water ingress, while the IK10 impact rating provides exceptional resistance to mechanical impact and vandalism. These characteristics make the fitting particularly suitable for exposed or high-traffic areas requiring dependable performance.
The integrated emergency functionality, rated at C40/C40, enhances safety by maintaining illumination during power interruptions, supporting compliance in environments where emergency lighting is critical. The fitting operates across a wide ambient temperature range from -30°C to 50°C, ensuring consistent performance in both cold and high-temperature conditions. With a rated lifespan of 50000 hours, the luminaire offers long-term operational efficiency with reduced maintenance requirements.
Designed for straightforward installation, the batten light is surface mounted and includes a 1.2m flex and plug for convenience. The integrated driver supports operation on 220-240V AC 50Hz supply, delivering stable and efficient electrical performance. Additional features such as its lightweight yet rugged construction and shatterproof diffuser further reinforce its suitability for warehouses, supermarkets, carparks and other demanding environments where reliable, high-output lighting is essential.
COLOUR: White
EMERGENCY: Yes (C40/C40 rating)
MATERIAL: Polycarbonate housing with frosted polycarbonate diffuser
DIMENSIONS: 1193mm (length) x 94mm (width) x 90mm (height)
APPLICATIONS: Warehouses, supermarkets, carparks, outdoor and vandal-prone areas
IP RATING: IP65 (fully weatherproof)
IK RATING: IK10 (impact and vandal proof)
LUMENS: 5514lm
COLOUR TEMP: 4000K (cool white)
GLOBE: LED (includes fixed LED chips in fitting)
CRI: 80
BEAM ANGLE: 120°
LIFE SPAN: 50000 hours
AMBIENT TEMP: -30°C to 50°C
DIMMABLE: No
WATTAGE: 40W
VOLTAGE: 220-240V AC 50Hz
INCLUDES: Flex & plug (1.2m AU flex & plug)
MOUNTING: Surface mounted
COMPLIANCE: LM80, RCM
PHOTOMETRIC DATA: Available upon request
WARRANTY: 1 year
