This LED batten light is a high-performance indoor lighting solution engineered to deliver adaptable and efficient illumination across a wide range of commercial and industrial environments. Constructed with a durable steel body and powder coated finish, combined with an opal diffuser, the fitting ensures strong structural integrity while maintaining a clean and functional profile. With overall dimensions of 1203mm x 64mm x 66mm, the luminaire is designed for surface mounting and incorporates conduit entry points at both ends, along with multiple knockouts to support flexible installation configurations.
Operating with a power adjustable LED system, the fitting allows selection between 23W, 28W, 33W, and 38W outputs, delivering up to 5700 lumens of high-efficiency illumination. With a colour rendering index of 80 and a wide 120° beam angle, the light provides consistent and uniform distribution, minimising shadows and ensuring effective coverage across the illuminated area. The integrated flicker free LED driver enhances visual comfort and supports stable lighting performance in demanding environments.
The luminaire features a Tri-CCT switching function, enabling selection between 3000K warm white, 4000K cool white, and 6000K daylight white colour temperatures. This flexibility allows the fitting to adapt to varying lighting requirements, from ambient settings to task-focused applications. With a rated lifespan of 50000 hours, the LED system is engineered for long-term durability and reduced maintenance over time.
Designed for installation efficiency and operational reliability, the batten includes multiple wiring access points to simplify setup in a variety of configurations. The IP20 rating confirms suitability for indoor use, while the robust construction ensures dependable performance in commercial and industrial applications. Backed by a 5 year warranty, this LED batten light provides a versatile and reliable lighting solution for offices, warehouses, and other interior environments.
COLOUR: White
MATERIAL: Steel body with powder coated finish and opal diffuser
WATTAGE: 23W / 28W / 33W / 38W (adjustable)
GLOBE: LED (includes fixed LED chips in fitting)
LUMENS: 5700lm
COLOUR TEMP: Switchable between 3000K (warm white), 4000K (cool white) and 6000K (daylight white)
CRI: 80
BEAM ANGLE: 120°
IP RATING: IP20 (indoors only)
DIMENSIONS: 1203mm (length) x 64mm (width) x 66mm (height)
LIFE SPAN: 50000 hours
DIMMABLE: No
FEATURES: Power adjustable output; Tri-CCT selectable; flicker free LED driver; conduit entry at both ends; multiple knockouts for flexible installation; opal diffuser for even light distribution
WARRANTY: 5 years
