This hand dryer is a high-performance surface-mounted solution engineered for reliability and efficiency in diverse commercial environments. Constructed from 3.0mm high-grade fire-retardant ABS, the unit features a robust housing secured by theft-resistant stainless steel hex drive screws to ensure long-term durability and safety. Its design is specifically optimized for accessible installations, maintaining full compliance with AS1428.1 guidelines when installed at the appropriate height.
Technically advanced, the system utilizes an automatic infrared sensor with an adjustable detection range between 100mm and 300mm to facilitate touch-free operation. The internal motor operates at speeds up to 3150 RPM, driving an air velocity of 20.5 meters per second to achieve a rapid drying time of 30 to 35 seconds. Integrated safety features include a 60-second power cut-off timer and a dual-thermostat system for the motor and the 1400W to 1700W heating element to prevent overheating during high-frequency use.
The unit offers significant operational flexibility with an adjustable power range from 1512W to 1800W, allowing for precise energy management based on site requirements. It operates on a standard 220V-240V voltage range and can be either hard-wired by a qualified electrician or connected via the provided cord and plug. With a noise level of approximately 55dB, it provides a relatively quiet user experience while maintaining the powerful airflow necessary for effective moisture removal in public washrooms.
Comprehensive compliance with international standards including CE, UL, RoHS, and ISO 14001:2015 underscores the product's quality and environmental responsibility. The manufacturer provides a 5-year warranty, covering replacement or repair for the first 3 years followed by 2 years of parts-only support, ensuring peace of mind for facility managers. This combination of fire-retardant materials, adjustable performance settings, and rigorous safety certifications makes it an ideal choice for modern infrastructure projects.
PRODUCT TYPE: Hand Dryer
APPLICATIONS: Suitable for accessible installations when installed in accordance with AS1428.1 guidelines
WARRANTY: 5 years (incorporating 3 years for replacement or repair and 2 further years for parts only)
COMPLIANCE: AS1428.1; CB; CE; UL; EMC; LVD; WEEE; RoHS; ISO 14001:2015; GreenSpec LISTED
COLOUR: White
MATERIAL: 3.0mm high grade fire retardant ABS
IP RATING: IPX1 (protected against light dripping or condensation)
VOLTAGE: 220V-240V (50-60Hz), 7.50A
WATTAGE: 1512W-1800W (adjustable)
DIMENSIONS: 216.99mm (height) x 259.99mm (width) x 179.99mm (depth)
WEIGHT: 3.5kg
MOUNTING: Surface mounted
NOISE: 55dB (+/- 3)
INSTALLATION: Hardwired or cord and plug (hex key supplied) - if hardwired then 80mm from the connection point to the wall; if cord and plug then 80mm from the connection point to the bottom of the unit
MOTOR SPEED: 2850 RPM (50Hz) - 3150 RPM (60Hz)
MOTOR SPECIFICATIONS: 1/8HP; 80W; designed with 105° thermostat
AIR SPEED: 20.5m/s (45MPH)
MOTOR CUT-OFF TIME: 60-sec power cut off (auto reset)
ENERGY CONSUMPTION:: 12.5Wh-15Wh per day
SENSOR TYPE: Auto infrared (180mm +/-20mm preset; 100-300mm adjust)
DRYING TIME: 30-35 seconds
HEATER ELEMENT: 1400W-1700W; designed with 87°C thermostat; 141°C auto reset safety cut off
WARM AIR: Speed: 14.5m/s; Temp: Ambient +20°
CASE SECURITY: 2 stainless-steel theft-resistant hex drive screws
FEATURES: Automatic operation; fire retardant housing
INCLUDES: Full instruction manual, installation manual and maintenance manual
