This ceiling fan with integrated LED light system delivers a high-performance airflow and lighting solution engineered for modern residential and covered outdoor environments. Driven by a precision-balanced 40W DC motor, it achieves stable rotational output with low acoustic disturbance while maintaining a peak airflow delivery of 15,600m³/hr. The 14° blade pitch is optimised to maximise volumetric flow efficiency across all six speed levels, producing consistent and evenly distributed air movement suitable for both cooling and seasonal recirculation.
The structural composition integrates durable materials designed for long-term operational reliability. The matt white body and canopy provide a clean architectural profile, while the oak ABS blades are engineered to minimise turbulence and deliver balanced aerodynamic performance. The PMMA lens cover protects the integrated LED module and contributes to uniform light diffusion. A 165mm ceiling canopy and a 10° hangsure design ensure stable mounting, and the overall installed height of 320mm maintains efficient air distribution without imposing excessive overhead clearance requirements.
Lighting performance is enhanced through an 18W fixed LED system offering a variable colour temperature range from 2700K to 6000K, allowing precise illumination control from warm ambient light to high-clarity daylight output. With a luminous performance of up to 1950lm and full-variable dimming capability, the lighting module supports diverse environmental and usage requirements. The integrated Smart Life WiFi remote system provides comprehensive operational control, including six fan speeds, summer/winter reverse mode, breeze mode, sleep mode, and programmable timers, all transmitted over a stable 433MHz signal.
Delivered with two downrods, an A23 12V remote battery and full WiFi remote functionality, this ceiling fan is designed for seamless installation by a licensed electrician and long-term durability in indoor and covered outdoor locations. The ABS and steel construction ensures corrosion resistance and mechanical integrity, while the 6-year warranty (3-year in-home plus 3-year motor coverage) and certification under approval number GMA-517404-EA reinforce its quality assurance. With its slimline design and intelligent control ecosystem, this fan provides a dependable, energy-efficient and aesthetically refined solution for contemporary spaces.
COLOUR: Matt White (body and canopy), Oak (blade)
MATERIAL: ABS (blades), Steel (body and canopy), PMMA lens cover
BLADES: 4
BLADE SPAN: 1320mm (52 inch)
BLADE PITCH: 14°
HANGSURE CANOPY: 10°
HEIGHT: 320mm
CEILING CANOPY: 165mm (diameter)
VOLTAGE: 220-240V AC 50-60Hz
MOTOR TYPE: DC
MOTOR WATTAGE: 40W
RPM: Up to 220
AIRFLOW EFFICIENCY: Up to 390m³/hr per watt
AIRFLOW: 15600m³/hr (Speed 6); 12700m³/hr (Speed 5); 9260m³/hr (Speed 4); 7900m³/hr (Speed 3); 6440m³/hr (Speed 2); 4860m³/hr (Speed 1)
GLOBE: LED (includes fixed LED chips in fitting)
LED WATTAGE: 18W
COLOUR TEMP: 2700K (warm light), 3000K (warm light), 4000K (cool white), 5000K (daylight white), 6000K (daylight white)
LUMENS: Up to 1950lm
LIFE SPAN: 30,000 hours at Ta25°C
DIMMABLE: Yes (variable dimming)
REMOTE CONTROL: Yes (WiFi; 6 speeds; reverse; breeze mode; sleep mode; fan off; timer 1hr/4hr/8hr; 433MHz)
REVERSIBLE: Yes (summer and winter mode)
INCLUDES: WiFi remote control; 1 x A23 12V battery (remote); 2 downrods
INSTALLATION: By licensed electrician only
APPLICATIONS: Indoor and covered outdoor applications
FEATURES: Smart Life app connectivity; slimline design
COMPLIANCE: GMA-517404-EA
WARRANTY: 6 years (3-year in-home + additional 3-years for motor)
