This ceiling fan integrates high-efficiency air circulation with advanced smart lighting control, delivering a refined climate management solution for modern residential and covered outdoor environments. Finished in matt black, the unit features a precisely balanced 3-blade aerodynamic assembly with a 1220mm (48 inch) blade span, driven by a high-performance 33W DC motor capable of rotational speeds of up to 220 RPM. The optimised 14° blade pitch is engineered to maximise airflow output while maintaining low acoustic output across all six operating speeds.

This ceiling fan produces a peak airflow of 17640m³/hr at maximum speed and achieves an efficiency rating of up to 369m³/hr per watt, ensuring powerful circulation with minimal power consumption. Progressive airflow modulation across six speed settings enables fine environmental control from gentle night-time air movement to high-velocity thermal equalisation. The fully reversible motor assembly allows for both summer cooling and winter heat redistribution for year-round operational efficiency.

This ceiling fan incorporates an integrated 18W LED light system with full variable dimming and multi-CCT selection ranging from 2700K through to 6000K, delivering a luminous output of up to 2120 lumens. Smart Life WiFi connectivity enables full lighting and fan control through the supplied WiFi remote, offering six fan speeds, reverse function, breeze mode, sleep mode, independent light control, CCT adjustment, and programmable timer off settings at 1hr, 4hr, and 8hr. Stable wireless communication is maintained via a 433MHz radio frequency system powered by an included A23 12V battery.

This ceiling fan is constructed entirely from engineered ABS for the body, canopy, and blades to ensure long-term structural stability and resistance to moisture-related degradation in indoor and protected outdoor locations. Operating on a 220-240V AC 50-60Hz electrical supply with an overall installed height of 310mm and a 10° hangsure canopy system, installation must be carried out by a licensed electrician in accordance with electrical safety standards. Backed by a comprehensive 6-year warranty comprising 3 years in-home service and an additional 3-year motor replacement period, this unit represents a durable and energy-efficient lighting and airflow solution for continuous residential use.

COLOUR: Matt Black
MATERIAL: ABS (body, canopy and blades)
BLADES: 3
BLADE SPAN: 1220mm (48 inch)
BLADE PITCH: 14°
HANGSURE CANOPY: 10°
HEIGHT: 310mm
CEILING CANOPY: 155mm (diameter)
VOLTAGE: 220-240V AC 50-60Hz
MOTOR TYPE: DC
MOTOR WATTAGE: 33W
RPM: Up to 220
AIRFLOW EFFICIENCY: Up to 369m³/hr per watt
AIRFLOW: 17640m³/hr (Speed 6 highest); 14200m³/hr (Speed 5); 13600m³/hr (Speed 4); 12800m³/hr (Speed 3); 11400m³/hr (Speed 2); 8500m³/hr (Speed 1)
GLOBE: LED (includes fixed LED chips in fitting)
LED WATTAGE: 18W
COLOUR TEMP: 2700K (warm light), 3000K (warm light), 4000K (cool white), 5000K (daylight white), 6000K (daylight white)
LUMENS: Up to 2120lm
LIFE SPAN: 35,000 hours at Ta25°C
DIMMABLE: Yes (variable dimming)
REMOTE CONTROL: Yes (WiFi; 6 speeds; reverse; breeze mode; sleep mode; light on/off; fan off; CCT selection; timer off only - 1hr 4hr 8hr; 433MHz)
REVERSIBLE: Yes (summer and winter mode)
INCLUDES: WiFi remote control; 1 x A23 12V battery (remote)
INSTALLATION: By licensed electrician only
APPLICATIONS: Indoor and covered outdoor applications
FEATURES: Smart Life app connectivity; slimline design; variable CCT; dimmable LED
COMPLIANCE: GMA-517681-EA
WARRANTY: 6 year warranty (3 year in-home + additional 3 year replacement on the motor only)
