This ceiling fan combines aerodynamic precision with advanced DC motor technology to deliver efficient, quiet and highly controlled airflow performance. Constructed with ABS blades, a steel body and canopy, and a PMMA lens cover, it is engineered for long-term reliability while maintaining a refined, slimline aesthetic suited to contemporary interiors. Presented in a matt black finish, its 1220mm (48 inch) blade span paired with a 10° blade pitch produces balanced and stable air movement, making it suitable for residential living rooms, bedrooms and covered outdoor areas where dependable year-round ventilation is required.
The fan incorporates a high-efficiency 45W DC motor capable of reaching rotational speeds of up to 235 RPM. This motor architecture offers smooth torque delivery and significantly reduced energy consumption when compared with traditional AC systems. At its highest setting, the fan produces airflow levels up to 10530m³/hr, supported by an airflow efficiency rating of up to 234m³/hr per watt. With six selectable speeds delivering precise gradations of airflow-from 2800m³/hr at low speed to full output at high-the system provides adaptable comfort control for varying seasonal and environmental conditions.
Integrated into the design is a 20W LED light source using fixed LED chips, delivering up to 2500 lumens of output. Its variable colour temperature system allows seamless selection between 2700K (warm light), 3000K (warm light), 4000K (cool white), 5000K (cool white) and 6000K (daylight white), supporting a wide range of illumination requirements. The light is dimmable, enabling fine-tuned luminance control for both task and ambient lighting. Remote operation is facilitated through the supplied WiFi-enabled remote control, offering access to 6 speeds, reverse functionality, breeze mode, sleep mode, fan off control, colour temperature selection and a programmable 1hr/4hr/8hr timer, all operating via 433MHz transmission.
Designed for secure installation with a 160mm diameter ceiling canopy, a 331mm overall height and a 10° hangsure canopy, this ceiling fan accommodates standard ceiling configurations while maintaining a low-profile architectural form. It is suitable for indoor and covered outdoor applications when installed by a licensed electrician in accordance with Australian standards. Backed by a 6-year warranty (3-year in-home service + 3 years on the motor) and tested to SGS-220783-EA compliance, this fan delivers a sophisticated, durable and energy-efficient airflow and lighting solution for modern residential environments.
COLOUR: Matt Black
MATERIAL: ABS (blades), Steel (body and canopy), PMMA lens cover
BLADES: 3
BLADE SPAN: 1220mm (48 inch)
BLADE PITCH: 10°
HANGSURE CANOPY: 10°
HEIGHT: 331mm
CEILING CANOPY: 160mm (diameter)
VOLTAGE: 220-240V AC 50-60Hz
MOTOR TYPE: DC
MOTOR WATTAGE: 45W
RPM: Up to 235
AIRFLOW EFFICIENCY: Up to 234m³/hr per watt
AIRFLOW: 10530m³/hr (Speed 6, highest); 9500m³/hr (Speed 5); 8100m³/hr (Speed 4); 7050m³/hr (Speed 3); 4800m³/hr (Speed 2); 2800m³/hr (Speed 1)
GLOBE: LED (includes fixed LED chips in fitting)
LED WATTAGE: 20W
COLOUR TEMP: 2700K (warm light), 3000K (warm light), 4000K (cool white), 5000K (cool white), 6000K (daylight white)
LUMENS: Up to 2500lm
LIFE SPAN: 50,000 hours at Ta25°C
DIMMABLE: Yes
REMOTE CONTROL: Yes (WiFi; 6 speeds; reverse; breeze mode; sleep mode; fan off; CCT selection; timer 1hr/4hr/8hr; 433MHz)
REVERSIBLE: Yes (summer and winter mode)
INCLUDES: WiFi remote control; 1 x A23 12V battery (remote)
INSTALLATION: By licensed electrician only
APPLICATIONS: Indoor and covered outdoor applications
FEATURES: Smart Life app connectivity; variable CCT; dimmable LED; low ceiling slimline design
COMPLIANCE: SGS-220783-EA
WARRANTY: 6 years (3 year in-home + additional 3 years on motor)
